Delta DOP-B10S615 DOP-B Series HMI Touchscreen

  • DOP-B Series HMI Touchscreen
  • 10.1 Inches Display Size
  • 1024 X 600 Pixel Resolution
  • 24 Volts Input


We provide all Delta human machine interfaces, delta hmi, human machine interface, human to machine interface, hmi interface, hmi interfaces, hmi human interface, human machine interface systems, hmi, dop-b10s615.

Delta 10″ Wide Screen, High Resoultion, Standard – DOP-B10S615

SPECIFICATIONS

10.1″ (1024 x 600 pixels) TFT LCD 65536 colors
3 sets of COM ports, support RS232 / RS422 / RS485
For data transfer/download: RS232, USB
Supports USB Host, direct connection to USB disk, printer and mouse
Supports SD card
Touch screen complies with IP65
Supports horizontal / vertical display
Editing software, DOPSoft is compatible with operating systems: Windows XP, Windows Vista, Windows 7

Downloads:

Delta DOP-B-User-Manual

Delta DOP-B-Catalog
